roduct Name
AVVR power cord
Product Application
AVVR cable, also known as copper core PVC insulated PVC sheathed flexible cable for installation, is a type of sheathed wire.
A represents the installation cable, the first V represents polyvinyl chloride (PVC) insulation, the second V - polyvinyl chloride (PVC) sheath, and R represents flexible structure wires and cables. Mainly refers to electronic cables with a core conductor cross-section of 0.4mm2 or less.
Purpose: Suitable for building intercom systems, security monitoring and alarm systems, internal wiring control wires for electrical appliances, signal control wires for computers, instruments, electronic equipment, and automation devices.
Product parameters
AVVR Executive Standard: JB8734-4-1998
Sheath: polyvinyl chloride;
Insulation: polyvinyl chloride
Conductors: multi-core bare copper wire, copper clad aluminum, etc
Rated voltage: 2271EC52 (300/300V)
Working temperature: not exceeding 70 ℃ Line color: black
Wire specifications: The commonly used specifications for wire cores are 0.12mm2, 0.2 mm2, 0.3 mm2, and 0.4 mm2,
The number of cores includes 2 cores, 3 cores, 4 cores, 5 cores, 6 cores, 7 cores, 8 cores, 9 cores, 10 cores, etc.
For example, AVVR3 * 0.2 wire is used, it means that the wire consists of three wire cores, each with a specification of 0.2mm2
