Product Name
HO5V-U
Product Application
Used for internal peripheral hard wiring between electrical and instrument distribution boards and power distributor wiring boards, as well as interfaces between electronic and electrical equipment and switchgear. Suitable for both power and lighting systems. Fixed laying of exposed and embedded conduits
Characteristics and compliance
Features: ◆ Solid core single core wire, easy to peel, easy to cut, and easy to install in accordance with EU coordinated standards
Compliant with certification: RoHS CE
Product structure
Wire: Single or stranded bare copper or tinned copper wire in accordance with IEC60228VDE02955 level standard
Insulation: PVC/T1 in accordance with DINVDE0281 Part 1+HD21.1
Color code: The wire core is identified by color and complies with HD402 standard
Application standard: HD213S3 VDE-0281Part-3 CE Low Voltage Directive 73/23/EECand93/68/EEC
Technical parameter
Rated voltage: 300V/500V
Test voltage: 4000V in accordance with DINVDE0281 Part 2+HD212
Minimum bending radius fixed laying: 12.5xD (cable outer diameter)
Mobile installation: 12.5xD (cable outer diameter)
Fixed laying temperature range: -30 to+80 ℃ -5 to+70 ℃
Mobile installation: smoldering and self-extinguishing
Flame retardancy: in accordance with IEC60332-1-2+EN60332-1-2ULVW-1+CSAFT1
Insulation resistance: 10MQxkm
